Through the Andasis Managed Fiber Copper Converting Device family, it is possible to easily convert from ETHERNET lines to Fiber Optic lines or from Fiber Opticlines to Gigabit ETHERNET lines.


  • The devices are available in industrial, rugged and commercial versions.
  • 155 Mb/s Dublex SC type Fiber Single Mode Optical Interface Single Mode 20/40/80/100 km options
  • 1000 Base-LX, 1.25Gb/s Dublex SC type Fiber Single Mode Optical Interface Single Mode 20/40/80/100 km options
  • 155 Mb/s Duplex LC type Fiber Single Mode Optical Interface Single Mode 20/40/80/100 km options
  • 1000 Base-LX, 1.25Gb/s Duplex LC type Fiber Single Mode Optical Interface Single Mode 20/40/80/100 km options

Compliance

  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3z

LAN: Bidirectional Copper and Fiber connection

  • Copper: 10/100/1000 BASE-T
  • Fiber: 100-FX or 1000 BASE-X

Connector

  • 1 or 2 x 10/100 Base-TRJ-45 port
  • 1 x 100 Base-FX SC tip Fiber Optic port
  • 1 or 2 x 10/100/1000 Base-T RJ-45 port
  • 1 x 1000 Base-FX SC tip Fiber Optic port

Certification

  • UL60950
  • FCC Class A
  • CE and UL A
  • 500.000/h MTBF

Operating and Storage Temperature

  • Low Temperature: -40 (Operation / Storage)
  • High Temperature: +70 (Operation / Storage)

Working and Storage Humidity Values

  • Low Humidity: -5% (Operation / Storage)
  • High Humidity: 95% (Operation / Storage)

Protection / Mounting

  • IP30, Rail Mounting Option (Optional)

Power Requirements

  • Power consumption lower than 5 Watt with 19-32V DC operation option
  • Reverse binding protection
