IOT UNITS AND VEHICLE TRACKING SYSTEM

IOT UNITS AND VEHICLE TRACKING SYSTEM

Andasis IoT Units are designed to be a common hardware unit in every field where the Internet of Things is used.

• Our product set consists of collectors and end units.
• MTC (Machine Type Communication) two units supported.

Provides the transfer and recording of location information of vehicles online and offline.

• LTE FDD: B1/B3/B5/B7/B8/B20 TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM:900/1800MHz
• GNSS : GPS,GLONASSBeiDou/Compass,Galileo,QZSS
• WIFI: 2.4G/5G 1TR×1RX IEEE 802.11a/b/g/n/ac WLAN 2.4
• 9 axis IMU (Inertial Mesarument Unit) : Gyroscope, Accelometer and Magnetometer
• Headset Output (3.5mm Audio Jack, Microphone+Speaker)
• 10/100/1000 Base-T Copper Interface
• USB-UART CLI (Micro USB Connector)
• USB 2.0 Interface (Micro USB Connector)
• MMC/SD Card Interface (SD Card Socket)

There are temperature, pressure gauge, accelerometer, angle metersensors in the terminal units.
The collector unit has a CAN interface for vehicle applications in addition to these sensors.
The Collector and Terminal unit communicate with each other and with the outside world via Bluetooth or ISM.
Units containing many features to be shared for different scenarios have a modular structureand can be customized according to the scenario.

• SIM Card Interface (SIM Card Socket)
• Operating with 3.7 Lithium Ion Chargeable Battery and USB interface
• -40 +70 Operating temperature range
